Description:

It is integrated screen printing with Digital printing, largely reduce the cost the dark garment printing, also by using discharge chemical, flock, foil, metallic, glitter to expand your business range. This Apparel printer is mainly choosed by Screen Printing factory, Branded Clothing Company, Designer, Fashion Company etc.

Features:

• Garment & Cutting Pieces & Grand Cutting Pieces, wider application.
• White screen + Digital CMYK printing Integrative design, lower cost.
• 6/10 printing stations design, higher efficiency.
• Automatic spaying system of pretreatment solution, more advanced technology.
• Quality silent ball screw, Y transmission shaft is more durable and stable.
• Servo system & fuzzy electric contral make repeat printing more accurate.
• Laser sensor design protect printhead safer.

Specifications:

Main Engine: Epson 7280 (double 5 colors)

Rip software: NS8 ( dark garment support)

Printhead: Epson TFP Printhead, 10*360 nozzle, VSDT

Colors: CMYK*2+ 2* white channels

Print Directions: Intelligent bi/single direction printing.

Speed: 5 minutes / 6 piece, 600 pieces per shift (light garments and women size)

Press Weight Load:  100kg (Nondistructive of resolution)

Resolution: 2400*1200dpi

Ink: Dupont Artistri® P5000⁺ textile pigment ink.

Media: Cotton, Polyester, Cotton/polyester Blends, Lycra, Viscose, Silk, Linen, Wool and more.

Other consumables: Pretreatment solution for dark & light garments, Cleaning ink and head cleaning kit.

Height adjustment: Automatic/ manual operation

Head protection: Laser sensor automatic protection system.

Power: 110-220V, 50-60HZ, 500W

Interface: USB2.0/1.1, 1GB Ethernet, 320M memory

Computer System: Windows XP/ Win7, Mac, Linus

Working Environment:  Temperature: 15-35℃, Humidity: 20-80RH

Size and Weight:   T6C:  Printer: 2860X1620X1250MM, 325kg

Package: 2900X1720X1430MM, 380kg

T10C:  Printer: 3750X1620X1250MM, 450kg

Package: 3850X1720X1430MM, 560kg

Printing Pallets:

Standard:  350mm*400mm (women size) :  T6C: 6 pieces.   T10C: 10 pieces.

Other options: 380mm*480mm (men size)

250mm*300mm(Children size)

1700mm*1080mm (Grand Pallet) for T6C

             2400mm*1080mm (Super Grand Pallet) for T10C
